Customer Pictures
These are pictures
sent from some of the customers who completed the subwoofer enclosure
projects from
plans purchased from HazeltonSound.com
All plans are
simple & designed for the novice wood worker, mainly to keep
the cost down, while out-performing pre-fabricated enclosures.
 |
This is Sean Legaspi's 98 Accord,
of Ontario, California
Built from our dual 12" plans.
His entire install was done very
quickly, he sent me the pictures with in days of getting
the plans.
I love the box covering design
pattern.
|
|
This is a very professional
looking system.
includes:
12" Treo SSI
Dual 4 ohm
2- Prefomance Teknique ICBM 9560/ 2400 watts max
1- Perfomance Teknique 4 Channel ICBM 775
2- Yellow Top Optima Batteries
|
|
This 4
-12" ported enclosure
is for a
2003 Chevrolet
Suburban.
The project was
completed from our plans by
Delane of Miami,
FL.
|
|
|
(Finished)
The first design
like this was in the Jeep Commander on
the install
gallery on the main page of this web site.
Delane says the box sounds
great.
Great job Delane!
|
|
|
|
This 3-12"
ported enclosure is for a
1999 Jeep Grand
Cherokee
The project
was completed from our plans by
John of Palm Bay,
FL.
|
This 4 -
12" ported enclosure is
for a
1996 Jeep Cherokee
The project
was completed from our plans by
Rejino Schaefer
of Eunice, LA.
|
|
|
|
The box was sprayed with
truck bed liner when done.
He also added his own
twist to the plans by putting
the highs on an angle
across the top of the box.
|
HeEmail:
I finished the box from the plans
you sent me for the two 12’s for my Blazer. It hits
hard!!! I haven’t even cranked it yet but from what
I have heard so far thumbs up! All I have is a KICKER ZX
300.1 mono amp pushing 2 brand new 12” Infinity Reference
subs. And the gain is just a little under half way turned
up, and my deck I have the subwoofer @ +0 & the Bass
@ 0 and it's still hitting! Before I had the sub turned
up all the way to +15 with some old 10” subs. I was
a little worried that I would have to upgrade to a ZX400.1
or ZX500.1 Kicker amp but not with this enclosure!
Well thanks again, If I ever need
to build another one I’ll go through you again.
Steve Martinez, Pomona, CA
|
|
|
|
Steve's project was done using
3/4" Particle board, not MDF, and
still sounds great. He got it done really quick too. He
just bought the plans a few days ago!
|
|
|
2008 Mazda CX-7
4-12" Ported Enclosure Build
from our plans,
Sits pretty tall in the trunk!
Very fast builder!
Sent the pics a few days after
buying the plans.
|
Robert Valdez
Des Plaines, IL
Email:
Here are the pics of the finished
box plans i bought from u mazda cx-7 let me know when u
post them so i can check them out.
Thanks THIS BOX ROCKS!!!!!
|
|
|
|
Here is Vince Call's (of Houston
TX)
Project for a 2000 Saturn SL Dual
12"
He added some bracing inside to make
the box more ridged.
|
|
Awesome job, love to
pics with work being done!
Waiting on the in-car
pics yet.
ebay feedback comment:
One of the best designs
for the Saturns it hits hard in my car.
|
|
|
|
This is from Derek Dudley
From St. Joseph, MO
3 - 12" Ported
box for a 1995 - 01 Explorer
|
Derek placed the 3-12" subwoofers
in a straight line.
Looks like it was a store bought
box, no store has that box!
Great job Derek!
|
|
Emails:
Single 18" Mazda 3
hello I don't know if you remember me I had
you design a box for 18in Treo sub wanted to let you know the box
is awsome went to a stereo comp. and beat everybody there. a guy
from JLaudio was doing the stereo comp.i metered 146.6db i only
had 1250rms pushing it thanks alot for the design and will send
pics when i get a chance and where would i send th pics to thanks
again
3-12" Jeep Cherokee
This design
is awsome I have 3 12" kicker comp 4
ohm, wired to 1 ohm on a 500 w max. amp they were
moving my nieghbors front window on negitive 7
bass and half volume. thank you for answering all
of my questions you are trully a good person thank
you. - XJKeith09-ebay
Please send in your pics of your Hazelton
designed projects, I love to post them.
Pictures I am looking for:
Step by Step Process
Finished before carpet or
covering
Finished & installed
in vehicle
Posing with your project
Vehicle pictured by the "Welcome
to" Sign of the city you are from.
Mix it up, combine a few
in one picture!
My goal with this page is
to make a gallery of each project, and a run down of the vehicle &
customer.
I will also post any other
info you may wish to have added.
